It is face-centered cubic lattice structure for use at temperature up to 1350°C (2460°F).The Nickel-Chromium alloy is characterized by excellent corrosion resistance of different kinds of media in both oxidation and reduction environments.
Chemical Content (%)
| Alloy |
% |
Ni |
Cr |
Mo |
Nb+N |
Fe |
Al |
Ti |
C |
Mn |
Si |
Cu |
P |
S |
|
Inconel
625
|
Min. |
58 |
20 |
8 |
3.15 |
|
|
|
|
|
|
|
|
|
| Max. |
|
23 |
10 |
4.15 |
5 |
0.4 |
0.4 |
0.1 |
0.5 |
0.5 |
0.5 |
0.015 |
0.015 |
Mechanical Properties
| Aolly state |
Tensile strength
Rm N/mm² |
Yield strength
R P 0.2N/mm² |
Elongation
A 5 % |
Brinell hardness
HB |
Density
g/cm³ |
Melting Point
°C
|
| 625 |
760 |
345 |
30 |
≤220 |
8.4 |
1290-1350 |
2.Features
Excellent corrosion resistanceat elevated and ambient temperatures,excellent resistance of the inorganic acid corrosion performance,excellent resistance of pitting and crevice corrosion,good machining and welding.
3.Usage
It is widely used in following field:
1)Marine Industries: it is used in sea-water for local mechanical stress attach.
2)Aerospace Industries.
3)Chemical Processing:the organic chemical process parts contains chloride,the digester and bleacherin the use of paper pulp and paper making industry,the equipment and parts in the use of acidic gas environments,acetic acid and anhydride reaction generator,sulfur acid cooling
4)Nuclear engineering:nuclear reactors
5)Pollution Control:Absorption tower, re-heater,gas import board, fan, blender, fair water fin, flue and so on.
4.Specification
Round Wire:0.03mm~10mm
Flat Wire(Ribbon):thickness 0.1mm~1.0mm,width 0.5mm~5.0mm
Strip:thickness 0.2mm~3.0mm,width 0.5mm~200mm
Other sizes are available upon your request.
5.Grade Contrast
ASTM(American Society for Testing and Materials):UNS N06625
DIN(Deutsche Industrie Normen):W.Nr.2.4856,NiCr22Mo9Nb
BS(British Standards):NA21
6.Products and services
1). Pass: ISO9001 certification, and SO14001cetification;
2). Fine after-sale services;
3). Small order accepted;
Our Services
1, We can provide a free sample for testing.
2,Customized lable, packing, OEM service
3,Mill test certificate will be provided after production, If it is necessary.
4,Good packing methods to keep goods no damage during delivery
5,We are cooperation with many famous forwarder, will try our best to choose the safty, convenience, quick, and cheap mode of transportation for our customers.
FAQ
How can I contact with your company?
Our sales team is ready to serve you via Email, Telephone , Fax or Skype You can reach us by below contact information:
What is your working time?
Monday-Friday : 8.0am-6.0pm (Beijing time, GMT+08.00)
We have public holiday during May.1-3, Oct.1-7 and our Chinese New Year holiday . For detail, please see our update holiday notice. During these period, if you have a demand, Please send me an email.
Do you provide free samples?
Yes, we can provide a free sample for testing, If we have sample in stock, The quantity based on the material type, The buyer should bear all the shipping costs.
What is your payment terms?
We accept 100% TT ( Telegraphic Transfer) in advance for small orders( value under USD 2000). For some big orders, we can accept 30% deposit, 70% balance before shipment. For very small orders , we can accept Western union payment. We are doing the best to match your demand.
